WKK - H-5R(4X) - Thin-wall heat shrink tubing - 4:1 - With adhesive - Halogen free - Operating temperature up to 125 °C

Starting at € 2.12 Excl. VAT

H-5R(4X) thin-wall heat shrink tubing (shrink ratio 4:1) contains co-extruded adhesive lining, which melts when the tubing is being shrinked, for better insulation and sealing. Applications include, among others, the sealing of electrical components in the automotive and communications industry. Flame retardant.

View versions and order

Skip to the end of the images gallery

Skip to the beginning of the images gallery

Versions

Color

Length (mtr)

As supplied: inner diameter in mm (min.)

After recovery: inner diameter in mm (max.)

Packaging type

Grouped product items
Art.no.	Color	Length (mtr)	As supplied: inner diameter in mm (min.)	After recovery: inner diameter in mm (max.)	After recovery: wall thickness in mm (min.)	Packaging type	Price excl. VAT	Stock (pcs.)
228382591	Transparent	30	24.0	6.0	2.8	On a reel	€ 337.44 Excl. VAT	22
228382501	Black	30	24.0	6.0	2.5	On a reel	€ 337.44 Excl. VAT	7
228352591	Transparent	30	16.0	4.0	2.1	On a reel	€ 181.81 Excl. VAT	Backorder
228352501	Black	30	16.0	4.0	2	On a reel	€ 181.81 Excl. VAT	172
228342801	Black	50	12.0	3.0	2	On a reel	€ 242.03 Excl. VAT	102
228333191	Transparent	75	8.0	2.0	1.6	On a reel	€ 284.92 Excl. VAT	Backorder
228333101	Black	75	8.0	2.0	1.6	On a reel	€ 284.92 Excl. VAT	38
228331591							€ 4.63 Excl. VAT	37
228323101	Black	75	6.0	1.5	1.35	On a reel	€ 201.72 Excl. VAT	4
2283142501	Black	1.22	52.0	13.0	2.9	Length piece	€ 833.70 Excl. VAT	Backorder
2283141591	Black	1.22	52.0	13.0	2.9	Length piece	€ 33.90 Excl. VAT	Backorder
228313391	Transparent	150	4.0	1.0	1.15	On a reel	€ 260.01 Excl. VAT	10
228313301	Black	150	4.0	1.0	1.15	On a reel	€ 260.01 Excl. VAT	37
228311591	Transparent	1.22	4.0	1	1.15	Length piece	€ 2.12 Excl. VAT	1779
2283112591	Transparent	30	32.0	8.0	2.8	On a reel	€ 433.09 Excl. VAT	12
2283112501	Black	30	32.0	8.0	2.8	On a reel	€ 433.09 Excl. VAT	Backorder
2283111591	Transparent	1.22	32.0	8.0	2.8	Length piece	€ 17.61 Excl. VAT	203

More Information
Brand	WKK
Heat shrink tubing model	Thin-wall (flexible) heat shrink tubing
Heat shrink tubing type	H-5R(4X)
Shrink ratio	4:1
Flame retardant	VW-1
Self-extinguishing	Yes
With adhesive	Yes
Printable	Yes
Operating temperature (°C)	-55 up to +125
Minimum shrink temperature (°C)	+70
Minimum full recovery temperature (°C)	+100
Longitudinal change	0 up to 10% max.
Material quality	Crosslinked co-extruded adhesive lined polyolefin
UL approval	UL224 125 ℃ VW-1 600 V file E204071
MIL-SPEC	Yes
UV resistant	Yes
Halogen-free	Yes
Master contract	240199
Meets	RoHS, Sony-SS-00259
